XTR Di2 REAR DERAILLEUR LONG CAGE 12s

RD-M9250-SGS

The all-new XTR M9250 long-cage derailleur paired with a standard 10-51T M9200 cassette gives riders and racers the speed, range, and robustness to tackle every trail on the mountain. With built-in Automatic Impact Recovery, an impact-deflecting shape, and simple covered-pulley solutions, this derailleur stands up to harsh trail impacts and still retains its lightning-quick shifting speed and top-level performance.

FEATURE

• Robust Design: A wide link structure, skid-plate design, durable carbon plate and solid pulley add robustness and longevity.
• RD Protection Function: The new Automatic Impact Recovery function instantly returns the derailleur to its original position after impact.
• SHIMANO SHADOW ES: A slimmer, stronger evolution of Shimano’s pioneering chain-stabilizing SHADOW concept.
• Precise & Clean Wireless Shifting: Wireless Di2 paired with HYPERGLIDE+ technology result in smooth, precise and instantaneous shifting.
• Wedge Shape: The new wedge shape of Shimano’s most survivable rear derailleur to-date avoids more direct impacts, and smoothly glances off rocks if there is a hit.
• Protected Battery: Tucked safely inside an enclosed space, the battery won’t budge even in rough terrain, while remaining completely removable for charging.

PRODUCT SPECIFICATION

• Model No: RD-M9250-SGS
• Series: XTR
• Rear speeds: 12
• Compatible chain: HG 12-speed
• Mount:
  • Direct attachment (conventional): ✔
• Max. front difference: 0T
• Total capacity: 41T
• Low Sprocket:
  • Max.: 51T
  • Min.: 51T
• Top Sprocket:
  • Max.: 10T
  • Min.: 10T
• Fluoric coated link bushings: 8
• Pulley:
  • Guide pulley bearing: Sealed bearing
  • Tension pulley bearing: Sealed bearing
  • Teeth: 13T
  • Sunken type pulley screw: ✔
• B-Axle:
  • Hollow Axle: ✔
• Di2 connectivity wireless:
  • Di2 shifting: ✔
  • Bluetooth® LE custom (*1)|Adjust mode information: ✔
  • Bluetooth® LE custom (*1)|Di2 battery level: ✔
  • Bluetooth® LE custom (*1)|Gear position: ✔
  • Bluetooth® LE custom (*1)|SHIMANO E-BIKE SYSTEMS data items (*3): ✔
  • Bluetooth® LE custom (*1)|Compatible with E-TUBE RIDE: ✔
  • Bluetooth® LE custom (*1)|Compatible with E-TUBE PROJECT: ✔
  • ANT private (*2)|Adjust mode information: ✔
  • ANT private (*2)|Di2 battery level: ✔
  • ANT private (*2)|Gear position: ✔
  • ANT private (*2)|SHIMANO E-BIKE SYSTEMS data items (*3): ✔
• SD50 port (pcs): 0
• SD300 port (pcs): 0
• SD50 connector (pcs): 0
• SD300 connector (pcs): 0
• LED for system status: ✔
