EXCEED

215

BOTTOM BRACKET STIFFNESS

215N/mm bottom bracket stiffness,
143N/mm head tube stiffness.

898

FRAME WEIGHT

M-size RDC frame with accessories.

15

HANDLEBAR SIZES

Perfect fit with Exceed Integrated Handlebar GEN 2.

2

SEATPOST SETBACK OPTIONS

0mm or 15mm offset seatposts available.

Crystal Finish

Why settle for ordinary when you can choose your road bike to express your personality?
The elegance of glossy shine, or the sleek matte look, the choice is yours.

All-Round Aerodynamics

Using the NACA Kammback airfoil shapes, not only provides incredible crosswind control but also maximizes aero benefit within the UCI regulations.
Exceed ultimately has excellent aerodynamic performance. Exceed outperforms in maximum power delivery and consistently helps  you in setting new speed records.

Tested Strength

Tested with 1200N at 120 revs per minute, totaling 100,000 revs. loaded pedal fatigue, as well as horizontal and vertical force fatigue. It outperforms the ISO 4210-6 safety standard for racing bikes by 20%.
Every Exceed is handcrafted, thoroughly inspected, and is covered by a limited lifetime warranty.

FUNCTIONAL SIMPLICITY

Hassle-free fully internal routing system for both mechanical and electronic systems. Clean, aerodynamic, and smooth shifting, it has it all.

Compare with other internal routing systems:

The front cable space has increased by 4.5mm, and smooths the curve of the headset cable angle by 10 degrees.

Tangible Lightness

Exceed offers two frame set versions, RDC the ultimate road racing frameset optimized through material and stacking solutions to ensure rigidity while carefully approaching weight limits.

Exceed Framset Specifications

Bottom Bracket

Threaded Bottom Bracket, T47 Inboard, 85.5mm width

Headset Bearing

Up & Lower：52mm*40mm*7mm*45/45 ACB

Axle

Front: 12 x 100mm thru-axle
Rear: 12 x 142mm thru-axle

Max Tire Width

(Actual)30mm

Saddle Clamp

Max: 7*11mm

Frame Weight
