Lightweight

Advanced-Grade Composite frame and fork keeps your ride lightweight so you can sail up climbs and accelerate quickly on paved or gravel roads.

Adventure-Ready

With clearance for 45c tires and mounts for racks, accessories and three water bottle cages, this bike meets the demands of your next epic ride.

Smooth Operator

Internal cable routing and D-Fuse seatpost and handlebars keep this gravel bike clean and contoured for vibration-damping comfort and less maintenance.

TECHS & FEATURES

ADVANCED COMPOSITE TECHNOLOGY

Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.

COMPACT ROAD DESIGN

When introduced by Giant in 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit.

D-FUSE SEATPOST

The proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride.

OVERDRIVE

Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

POWERCORE

A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.

TUBELESS SYSTEM

Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.

MEGADRIVE

A massive rectangular downtube and oversized toptube work in unison to provide superior front end lateral and torsional steering precision. The precisely engineered, rectangular shaped downtube yields unprecedented steering and pedaling stiffness.

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with us to determine the correct size.

• XS: 150cm to 163cm
• S: 158cm to 169cm
• M: 164cm to 175cm
• L: 170cm to 181cm

• Sizes: XS, S, M, L
• Colors: Kelp Forest
• Frame: Advanced-Grade Composite, 12x142mm thru-axle, disc
• Fork: Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
• Shock: N/A
• Handlebar: Giant Contact XR D-Fuse, 31.8 XS:40cm, S:40cm, M:42cm, L:42cm
• Grips: Liv All Condition
• Stem: Giant Contact XS:70mm, S:80mm, M:90mm, L:90mm
• Seatpost: Giant D-Fuse, composite XS:75mm travel, S:75mm travel, M:75mm travel, L:100mm
• Saddle: Liv Approach
• Pedals: N/A
• Shifters: Shimano GRX RX-600, 2x11
• Front Derailleur: Shimano GRX RX-810
• Rear Derailleur: Shimano GRX RX-810
• Brakes: Shimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
• Brake Levers: Shimano GRX RX-600 hydraulic
• Cassette: Shimano 105, 11-speed, 11x34
• Chain: KMC X11SL-1
• Crankset: FSA Omega AGX, 32/48 XS:165mm, S:170mm, M:172.5mm, L:172.5mm
• Bottom Bracket: Praxis, press fit
• Rims: Giant P-X2 Disc wheelset
• Hubs: Giant P-X2 Disc wheelset
• Spokes: Giant P-X2 Disc wheelset
• Tires: Giant CrossCut AT 1, 700x38c, tubeless
• Extras: tubeless prepared, 45mm max tire size
