Liv Avail AR 3 Advanced-Grade Composite Road, Gravel Bike Shimano Sora - Frost Blue
Liv Avail AR 3 Advanced-Grade Composite Road, Gravel Bike Shimano Sora - Frost Blue
Regular price
₱57,000.00
Regular price
Sale price
₱57,000.00
Unit price
per
Tax included.
SKU:
Couldn't load pickup availability
Avail AR 3
Whether it’s navigating asphalt or venturing through an unpaved short cut, the Avail AR is smooth on flats, spry on climbs and confident on descents.
Key Performance Factors
- Comfort: The lightweight ALUXX aluminum frame features the latest endurance geometry with an Advanced-grade composite fork and D-Fuse seatpost to diminish vibrations.
- Control: The 32c tires provide stability on both road and off-road surfaces, with compatibility for tubeless tires up to 38c. The OverDrive steerer and powerful disc brakes ensure precise handling and reliable stopping power, giving you confidence on any terrain.
- Carrying Capacity: Equipped with frame mounts for racks and fenders, the Avail AR ensures you're ready for longer journeys with all the necessary gear and protection.
Geometry
| XS | S | M | L | |
| Seat Tube Length (mm) | 410 | 445 | 480 | 515 |
| Seat Tube Angle | 74.5° | 74.5° | 74.0° | 74.0° |
| Top Tube Length (mm) | 515 | 525 | 540 | 555 |
| Head Tube Length (mm) | 118 | 138 | 158 | 178 |
| Head Tube Angle | 70.5° | 71.5° | 72.0° | 72.0° |
| Fork Rake (mm) | 53 | 53 | 53 | 53 |
| Trail (mm) | 69.5 | 62.9 | 59.6 | 59.6 |
| Wheelbase (mm) | 999 | 1001 | 1006 | 1022 |
| Chain Stay Length (mm) | 422 | 422 | 422 | 422 |
| Bottom Bracket Drop (mm) | 80 | 80 | 80 | 80 |
| Stack (mm) | 538 | 561 | 582 | 601 |
| Reach (mm) | 366 | 369 | 373 | 383 |
| Stand Over Height (mm) | 681 | 709 | 736 | 766 |
| Handlebar Width (mm) | 380 | 400 | 400 | 420 |
| Stem Length (mm) | 70 | 80 | 90 | 90 |
| Crank Length (mm) | 165 | 170 | 170 | 172.5 |
| Wheel Size | 700C | 700C | 700C | 700C |
Sizing
| XS | 5’0” to 5’4” |
| S | 5’2” to 5’7” |
| M | 5’5” to 5’9” |
| L | 5’7” to 6’0” |
Specs
| Fork | Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc |
|---|---|
| Hubs | Giant alloy, 12mm thru-axle |
| Rims | Giant S-R2 Disc wheelset |
| Stem | Giant Sport XXS: 70mm, XS: 70mm, S: 80mm, M: 90mm, L: 90mm |
| Chain | KMC X9 |
| Frame | ALUXX-grade aluminum, 12x142mm thru-axle, disc |
| Tires | Giant S-R3 AC, 700x32c |
| Brakes | Tektro MD-C550 mechanical, Shimano rotors [F]160mm, [R]160mm |
| Saddle | Liv Approach |
| Spokes | Stainless |
| Crankset | Shimano Sora, 34/50 XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm |
| Seatpost | Giant D-Fuse, alloy XXS: 300mm, XS: 300mm, S: 300mm, M: 350mm, L: 350mm |
| Shifters | Shimano Sora |
| Handlebars | Liv Connect, 31.8mm XXS: 380mm, XS: 380mm, S: 400mm, M: 400mm, L: 420mm |
| Tape/Grips | Liv All Condition |
| Brake Levers | Shimano Sora |
| Bottom Bracket | Cartridge |
| Rear Derailleur | Shimano Sora |
| Front Derailleur | Shimano Sora |
| Cassette/Freewheel | Shimano CS-HG400, 9-speed, 11x34 |
