Get ready for long, exciting rides with this wheelset. Its wide rim provides enhanced comfort so you can tackle those miles with ease. Feel the thrill of speed as you glide effortlessly along the road, with every pedal stroke transferred to the road thanks to the reliable Ratchet system. This wheelset is designed to give you the perfect blend of reliability, comfort and fun to make your rides truly memorable.

• E 1800 SPLINE 23: the lighter rim will let you enjoy the scenic views from the hills you might encounter on the way
• E 1800 SPLINE 30: increase your speed thanks to an aero optimized rim design

• HUB TYPE: 370 with Ratchet LN 18
• RIM: Aluminum, Hooked / Crotchet tubeless TC
• RIM HEIGHT: 23 mm, 30 mm
• SPOKES: DT aero comp® wide straightp, DT new aero® II straightpull

RIM WIDTH

The 22mm internal rim width is ideal for mounting wide tires, providing comfort and stability when riding at lower pressures.

RIM HEIGHT

The new aero optimized E 550 and its 30mm height will assist you in riding faster.

SPOKES

The DT new aero® straightpull features an improved aero shape thanks to the flat forging process.

HUB

The upgrade of the 370 hub to the Ratchet LN system results in increased reliability while motivating you with its signature freewheeling sound.

FREEHUB BODY

The Ratchet LN System achieves greater reliability by simultaneously engaging each tooth compared to the pawl system and its relatively smaller engagement surfaces.

AERO FOR ALL

Our first aero-optimized aluminum wheels

TECHNOLOGY

We believe in the art of engineering and strive for sophistication in the product development process. Our guiding idea is to constantly push barriers with our inhouse developed technologies.

FRONT WHEEL SPECIFICATION

W0E1800AIDXSA21183 - E 1800 SPLINE 30 DB 12/100 MM

General

• Net Weight: 880g
• Recommended System Weight Max.: 130kg
• ASTM Classification: 2

Rim

• Material: Aluminum
• Rim Joint: Sleeve joint
• Tire Interface: Hooked/Crotchet tubeless TC
• Valva Hole: Presta
• Rim Diameter: 29"/700C
• Rim Height: 30mm
• Inner Width: 22mm
• Outer Width: 26mm
• Cross-Section:

Hub

• Hub Type: 370
• Axle System: 12mm Thru Axle
• Built-In Dimension: 100mm
• Brake Interface: Disc Center Lock

Spokes & Nipples

• Spokes Left: DT aero comp® wide straightp
• Spokes Right: DT aero comp® wide straightp
• Spoke Pattern: Two-cross (1:1)
• Nipples: DT ProLock Squorx ProHead alu

Inclusive

• Inclusive:
• Tubeless tape 25mm
• TL valve alu black 26-35mm

REAR WHEEL SPECIFICATION

W0E1800NIDMSA21184 - E 1800 SPLINE DB 30 12/142 MM SHIMANO

General

• Net Weight: 1010g
• Recommended System Weight Max.: 130kg
• ASTM Classification: 2

Rim

• Material: Aluminum
• Rim Joint: Sleeve joint
• Tire Interface: Hooked/Crotchet tubeless TC
• Valve Hole: Presta
• Rim Diameter: 29"/700C
• Rim Height: 30mm
• Inner Width: 22mm
• Outer Width: 26mm
• Cross-Section:

Hub

• Hub Type: 370
• Axle System: 12mm Thru Axle
• Built-In Dimension: 142mm
• Brake Interface: Disc Ceneter Lock
• Cassette Interface: Shimano ROAD
• Freehub Body: Shim. RD. 11SP Forged (ASF11)
• Freehub System: Rachet LN 18

Spokes & Nipples

• Spokes Left: DT aero comp® wide straightp
• Spokes Right: DT aero comp® wide straightp
• Spoke Pattern: Two-cross (1:1)
• Nipples: DT ProLock Squorx ProHead alu

Inclusive

• Inclusive:
• Tubeless tape 25mm
• TL valve alu black 26-35mm
