BMC URS AL TWO Premium Aluminum Gravel Bike, GRX - Dark Petrol / Off-White

BMC URS AL TWO Premium Aluminum Gravel Bike, GRX - Dark Petrol / Off-White

₱110,000.00
₱110,000.00
Sale Sold out
Tax included.
Size

SKU:

URS AL TWO

DARK PETROL / OFF-WHITE

Shimano GRX 600 1x Drivetrain
PRD23 Wheelset
Fender, Rack and Cargo Mounts

URS AL is the bicycle equivalent of a chameleon, able to adapt and perfectly fit in to diverse surroundings. Maintaining the URS family’s ride and handling characteristics, and offering even greater practicality, through additional cargo mounts and dropper post compatibility, URS AL can truly be your bike for all reasons.

Technical Overview

Specs

Frameset

  • Frame: URS Premium Aluminium | Gravel+ Geometry | Internal Cable Routing | Fender and Rack Mounts | PF86 Bottom Bracket | Flat Mount Disc12x142mm Thru-Axle
  • Fork: URS Carbon | Internal Brake & Hub Dynamo Cable Routing | Fender Mounts | Cargo Mounts | Flat Mount Disc | 12x100mm Thru-Axle | Side Mounts

Cockpit

  • Handlebar: BMC RAB
  • Stem: BMC MSM02
  • Seatpost: BMC RSP03
  • Saddle: Selle Royal SRX

Drivetrain

  • Gears: 1x11
  • Crankset: Shimano GRX FC-RX600 40T
  • Cassette: Shimano SLX CS-M7000 11spd 11-42T
  • Chain: CN-HG601-11 11spd
  • Rear Derailleur: Shimano GRX RD-RX812
  • Shifters: Shimano GRX BL-RX600

Brakes

  • Brake Levers / Calipers: SHIMANO GRX BR-RX400
  • Rotors: SHIMANO SM-RT64 160 / 160mm

Wheels

  • Rims: PRD23 - 23mm
  • Hubs (F/R): CL-712 (F) / RXC-142S (R) | Thru Axle
  • Tires: WTB Riddler - 45mm

Additional Information

  • Tire Clearance: 45mm (Measured Width)
  • ASTM Classification: Level 2
  • Weight Limit: 120 Kg

Geometry

Size XS S M L XL
Rider Height < 165 162-172 170-182 180-192 >190
Reach 390 400 410 420 430
Stack 525 550 580 610 640
Bar Drop 130 130 130 130 130
Bar Reach 70 70 70 70 70
Bar Width 420 420 420 440 440
BB Drop 69 69 69 69 69
Crank Length 170 170 172.5 172.5 175
Fork Length 410 410 410 410 410
Fork Rake 45 45 45 45 45
Front Center 608 626 647 668 689
Head Tube 92 118 150 182 214
Head Tube Angle 70 70 70 70 70
Rear Center 430 430 430 430 430
Seat Angle 74 74 74 74 74
Seat Tube 430 445 475 505 540
Seatpost Length 350 350 350 350 350
Seatpost Offset 15 15 15 15 15
Standover Height 720 738 768 797 830
Stem Angle ±6 ±6 ±6 ±6 ±6
Stem Length 70 70 70 80 80
Top Tube 540 558 576 595 614
Trail 78 78 78 78 78
Wheelbase 1028 1047 1068 1089 1110
